Palm Fruit Thresher
Palm Fruit Thresher
Drum type thresher for separating palm fruit from bunches after sterilization, with high separation efficiency and low fruit damage rate.
Main Parameters
| Type | Rotary Drum Thresher |
| Application | Palm Fruit Separation from Bunches |
| Capacity | 3-50 TPH |
| Threshing Rate | > 95% |
| Motor Power | 18.5-75 kW |
| Material | Stainless Steel 304 |
| Warranty | 12 Months |
Product Models
| Model | Capacity | Power | Dimension (mm) | Weight |
|---|---|---|---|---|
| TDM-150 | 3-5 TPH | 18.5 kW | 2500×1800×2000 | 2,800 kg |
| TDM-250 | 6-12 TPH | 37 kW | 3200×2200×2300 | 4,200 kg |
| TDM-350 | 13-20 TPH | 75 kW | 3800×2500×2500 | 5,800 kg |
Product Details
The palm fruit thresher is designed to separate palm fruit from sterilized fruit bunches. After sterilization, the fruit becomes loose and can be easily detached from the bunch using the rotating drum mechanism. The rotary drum design ensures efficient separation of palm fruits from empty fruit bunches with high throughput.
Key Features:
- High threshing efficiency above 95%
- Rotary drum design for continuous operation
- Low fruit damage rate preserves fruit quality
- Adjustable rotation speed for different bunch conditions
- Durable stainless steel construction
- Easy maintenance with accessible components
Working Principle:
Sterilized fruit bunches are fed into the rotating drum where mechanical action separates fruits from bunches through perforated screens. The rotation creates tumbling action that gently detaches the fruit while minimizing damage. Separated fruits fall through the screen openings, while empty bunches are discharged from the drum end for further processing.
